- Displacement:7mL/rev
- Flow Rate Range:5–6.5L/min
Precision Micro-Flow Delivery for Demanding Applications
Designed for applications where every milliliter matters, this micro-flow magnetic gear pump provides precise and consistent fluid delivery under demanding operating conditions. The magnetic drive eliminates the need for a dynamic shaft seal, helping reduce leakage and maintenance requirements. With excellent low-flow control and high-pressure capability, it is an ideal choice for precision fluid handling, hydrogen systems, battery equipment and laboratory instruments.
Material
Pump casing：SS316L
Gear：peek
Gear shaft：SS316L or nano-ceramic
Internal magnetic drive：PPS overmolded magnet
Sealing ring：FKM/PTFE/FFKM
Optional Motor Configurations
DC Motors (24V): Brushless Motor
AC Motors (220V/380V): Three-Phase Motor, Servo Motor
