- Displacement:6mL/rev
- Flow Rate Range:2–2.5L/min
Even at Ultra-Low Flow Rates, Stable High-Pressure Output
The micro-flow magnetic gear pump is specifically designed for precision fluid transfer. With precision gear meshing and magnetic drive technology, it provides stable and reliable delivery of small amounts of liquid. Even under relatively high system pressure, the pump maintains excellent flow control performance. Its seal-free magnetic drive design helps minimize leakage and maintenance requirements, making it suitable for low-flow, high-pressure and continuous-operation applications.
Material
Pump casing：SS316L
Gear：peek
Gear shaft：SS316L or nano-ceramic
Internal magnetic drive：PPS overmolded magnet
Sealing ring：FKM/PTFE/FFKM
Optional Motor Configurations
DC Motors (24V): Brushed Motor, Brushless Motor, Stepper Motor
AC Motors (220V/380V): Three-Phase Motor, Servo Motor
